uPVC or rigid PVC is the most frequently used material for windows in Germany. Due to its excellent value for money, low maintenance, and its very good thermal insulation properties, uPVC is often the number one choice for windows and doors in Europe.
Download 2024 uPVC PRODUCT CATALOG [pdf 0.7MB].
|
| Schuco Corona CT 70 |
 |
With high thermal insulation and versatile accessories, Schuco Corona CT 70 has timeless lines, narrow face widths and very effective sound reduction. In a single family home from 1980 with approx. 1500 ft² usable area, new windows from the Schuco Corona CT 70 profile system consume about 20% less energy than old windows. Schuco Corona CT 70 is available as a rebate gasket system with two drainage levels and also as a center gasket system with an additional third drainage level.
- Good thermal insulation: Uf values from 0.21 to 0.26 Btu/(hr·ft²·F°)
- A choice of three contours (Classic, Rondo, Cava)
- High level of sound reduction and weather resistance
- Versatile color and design options
|
|
| Schuco Corona SI 82 (LivIng) |
 |
Thanks to three drainage levels and the 5-chamber technology Schuco Corona SI 82 door systems achieve excellent thermal insulation properties. An extensive range of accessories ensures a high level of system security.
- 5-chamber profile system with a basic depth of 82 mm
- Narrow face widths
- Designed for use with standard fittings
- Excellent thermal insulation through thermal break in threshold area
- Easy access combination threshold in accordance with DIN 18025, either made of glass fiber reinforced plastic or aluminum
- Increased basic depth for more security and protection against break-ins
- Vent geometry with rebated appearance
- Three drainage levels for optimum protection against wind, rain and noise
- Silver-grey gaskets on white profiles for an elegant appearance
- Concealed drainage
|
|
| Schuco AluInside SI 82 |
 |
With its outstanding thermal insulation properties, the Schuco AluInside energy-saving window provides both exclusivity and a sense of well-being. Schuco AluInside energy-saving windows allow you to save up to 33 % of your previous energy requirements when replacing your old windows with new ones. In the case of a traditional single family home, that can be as much as 380 gallons of heating oil per year. At the same time, you help the environment by reducing CO2 emissions by approx. 10 thousand pounds.
- Maximum thermal insulation: Uf value of 0.134 Btu/(hr·ft²·F°)
- Patented composite constructions in uPVC and aluminum
- High basic depth with well-concealed fittings
- Versatile color and design options
|
|
|
| |
AluInside |
SI 82 |
AWS 90 |
|
| Description |
PHI Certified uPVC Windows |
Passive House Spec Best-Value uPVC Windows |
PHI Certified Aluminum Windows |
|
| Manufacturer |
Schuco |
Schuco |
Schuco |
|
Frame Width
(below/above/sides) |
4.72 |
4.72 |
4.61 |
in |
Uf-Value Frame
(below/above/sides) |
0.133 / 0.134 / 0.134 |
0.194 / 0.194 / 0.194 |
0.176 / 0.176 / 0.176 |
Btu/(hr·ft2·F) |
Ψ-Spacer
(below/above/sides) |
0.016 |
0.016 |
- |
Btu/(hr·ft2·F) |
| Uf-Value Frame |
0.133 |
0.194 |
0.176 |
Btu/(hr·ft2·F) |
| Ucog-Value Glass |
0.088 |
0.088 |
0.088 |
Btu/(hr·ft2·F) |
| Uw-Value Window |
0.114 |
0.134 |
0.128 |
Btu/(hr·ft2·F) |
|
|
|
|
|
|
|
| |
|
